Main specifications
Lock
With opposing blades and double track key with internal profile.
Stator
Glossy chrome-plated zinc alloy.
Rotor
Chrome-plated zinc alloy with drill-proof hardened steel plate and stainless steel front plate.
Nut
M19x1 in brass.
Spring washer
Zinc-plated steel.
Closing lever
Zinc-plated steel, thickness 2.5 mm.
Screw
M5x5 zinc-plated steel.
Two reversible keys
Nickel-plated brass, removable in two positions at 180°.
Rotation
180°.
Standard executions
- CXA./CXB: lock with 15,660 different combinations: each lock has a couple of keys with different combination.
- CXAU./CXBU: lock with one combination: all locks have the same combination which can be opened with one key.
