Specification
Types
Type MCR: matt chrome plated
Type MCRS: matt chrome plated, standard scale 0...90,
100 graduations, acc. scale scheme d1/100 A RA 0-10-20...90/10
Bore codes
- Version B: without friction ring
- Version R: with friction ring
- matt chrome plated with standard scale MCRS
Scale
engraved with laser precision, black
Information
The non-wearing friction ring ensures perfect engagement of the scale ring when re-aligning the spindle. In addition it allows the setting of the scale ring on a static shaft.
Also this scale rings can be supplied with any type of graduation.
Regarding design, numbering run, numbering position and numbering sequence of the scale please see the layout for scale rings on the order sheet "How to order graduations"
